Technical Specifications
| Speed Feedback Type: | Analog Tacho |
| Keypad/User Interface Option: | 6901 keypad fitted |
| Output Current Rating: | 830A |
| Modes of Control: | Four Quadrant / Regenerative |
| Aux Supply Input Voltage: | 1*230VAC |
| Special Option: | Airflow Kit |
| Option Board Type: | N/A |
| Input Voltage: | 3*220-500VAC |
| Frame Size: | 4 |
| Drive Axis Type: | Single Axis Technology |
| Product Series: | DC590 |
| Continuous Output Current Rating: | 15 to 1950 A |
| Brand: | Parker |
| Product Type: | DC Drive |
| Compatible Motor Type: | DC Brushed Servo |
| Compatible Feedback Device: | Armature Voltage, Tachometer, Encoder |
| Communication Interface: | RS232/RS485, CANopen, ControlNet, DeviceNet, Profibus, Ethernet TCP/IP, LinkNet, Modbus |
| Specifications Met: | CE (EMC & LVD), Overvoltage Category III, Pollution Degree II, UL Listed, cUL Listed |
| Operating Altitude: | up to 500 m ASL (derate > 500m) |
| Output Power: | 1 to 1200 HP |
| Overload Rating: | 150 % for 30s, 200 % for 10s (depending on drive output current, refer to manual for details) |
| Operating Temperature: | 32 to 113 °F for 15-165A drives (derate up to 131°F max.), 32 to 95 °F for 180-270A drives (derate up to 131°F max.), 32 to 104 °F for 380-1950A drives (derate up to 131°F max.), 0 to 45 °C for 15-165A drives (derate up to 55°C max.), 0 to 35 °C for 180-270A drives (derate up to 55°C max.), 0 to 40 °C for 380-1950A drives (derate up to 55°C max.) |
